MU0077 Molybdenum Rod & Molybdenum Bar (Mo Rod & Mo Bar)
| Catalog No. | MU0077 |
| Size | >4.0mm Dia. x L |
| Standard | ASTM B387 |
| Density | 9.8 - 10.2 g/cc |
| Material | Mo≥99.95% & TZM |
| Surface | Polished, Chemical cleaned |
| MSDS/SDS |
Explore our premium selection of Molybdenum Rods & Bars on Stanford Advanced Materials (SAM). Renowned for their exceptional material properties, our offerings boast high purity and superior strength. With a commitment to professionalism and quality, our platform ensures reliable sourcing for diverse industrial applications.
Related products: TZM Products, Mo-La Products, Mo Tube, Mo Sheet, Mo Wire, Mo Plate, Mo Disc
INQUIRY
Add to Inquiry List
Description
Specification
Technical Data Sheet
Video
Molybdenum Rod & Molybdenum Bar Description
Molybdenum Rods (Mo Rod) and Bars (Mo Bar) find widespread applications across industries. Their high melting point and strength make them essential in manufacturing heating elements, electrical contacts, and aerospace components. These versatile materials also play a crucial role in the production of glass and steel, providing stability and resilience in demanding conditions. Additionally, Mo Rods and Bars are utilized in research and development for their unique properties, contributing to advancements in various technological fields.
Molybdenum Rod & Molybdenum Bar Specifications
We carry a full line of standard rods and bars. Apart from this, our moly bars and moly rods are available in various dimensions upon your request.
* Mo Rod
|
Dia. (inch) |
Len. (inch) |
Dia Tlrnc. (inch) |
Len Tlrnc. (inch) |
|
0.08 - 0.40 |
<315 |
±0.005 |
+0.08, -0 |
|
0.40 - 0.80 |
<118 |
±0.010 |
+0.08, -0 |
|
0.80 - 4.00 |
<78 |
±0.015 |
+0.08", -0 |
|
>4.00 |
<40 |
±0.025 |
+0.08, -0 |
|
Typical Dimensions |
|||
|
.040″ Dia x R/L |
.050″ Dia x R/L |
.060″ Dia x R/L |
.062″ Dia x R/L |
|
.080″ Dia x R/L |
.090″ Dia x R/L |
.125″ Dia x R/L |
.250″ Dia x R/L |
|
.500″ Dia x R/L |
.625″ Dia x R/L |
.750″ Dia x R/L |
.875″ Dia x R/L |
|
1.000″ Dia x R/L |
1.125″ Dia x R/L |
1.250″ Dia x R/L |
1.500″ Dia x R/L |
|
2.000″ Dia x R/L |
2.500″ Dia x R/L |
3.000″ Dia x R/L |
3.250″ Dia x R/L |
|
3.750″ Dia x R/L |
4.000″ Dia x R/L |
4.500″ Dia x R/L |
5.000″ Dia x R/L |
* Mo Bar
|
Wd. (mm) |
Tck. (mm) |
Len. (mm) |
Len Tlrnc. (mm) |
|
15 |
15 |
600 |
+1, -0 |
|
20 |
20 |
1000 |
+1, -0 |
|
45 |
45 |
1200 |
+2, -0 |
|
60 |
60 |
1500 |
+3, -0 |
* Surface Finish of Molybdenum Rod & Molybdenum Bar
We offer three types of surface finish as followed:
- Cleaned: the surface is chemically cleaned to remove all lubricants and oxides.
- Black: the surface is either as swaged or as drawn and retains a coating of processing lubricants and oxides.
Ground: the surface is center-less ground to remove all coating and to achieve precise diameter control.
Molybdenum Rod & Molybdenum Bar Application
- Used in steel-making additives, electric vacuum parts, gas pipes, lead wire, sidebar, daily-use glass, optical glass, insulation material, and glass fiber.
- Used to stretch into molybdenum wire and molybdenum electrode.
Molybdenum Rod & Molybdenum Bar Packaging
Our molybdenum rods and molybdenum bars are carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
Molybdenum Rod & Molybdenum Bar FAQs
Q1: What are molybdenum rods and bars used for?
A1: Molybdenum rods and bars are used in a wide range of industries and applications, including:
Aerospace and Defense: For high-performance components exposed to extreme heat
Electronics Manufacturing: As electrodes, contacts, and filaments in high-temperature environments
Mold Making: Used for producing high-temperature mold components
Manufacturing Equipment: In high-temperature furnaces and reactors
Research and Development: For material testing and custom applications
Welding: As an alloying element or welding rod
Q2: How are molybdenum rods and bars packaged?
A2: Molybdenum rods and bars are packaged to prevent damage and contamination during transport:
Protective packaging such as foam or vacuum-sealed bags
Custom packaging options are available depending on size, quantity, and shipping requirements
Q3: Can I order custom molybdenum rods and bars?
A3: Yes, we offer customized molybdenum rods and bars in various lengths, diameters, and shapes to meet your specific needs. Please contact our team to discuss your requirements and receive a tailored solution.
