NT0401 Nitinol Wire & Nitinol Rod, Nickel Titanium
| Catalog No. | NT0401 |
| Material | Titanium Nickel Alloy |
| Standard | ASTM F2063 |
| Density | ~6.45g/cm3 |
| Surface | Black or Pickled or Polished |
Nitinol Wire & Rod is well known for its thermo-mechanical properties of superelasticity and shape memory effect. Stanford Advanced Materials (SAM) has rich experience in manufacturing and supplying high-quality Nitinol Products.
Related products: Nitinol Strip/Nitinol Foil, Nitinol Spring, Nitinol Sheet
INQUIRY
Add to Inquiry List
Description
Specification
SDS
Video
Nitinol Wire & Rod Description
Nitinol Wire & Nitinol Rod are the fabricating products of nickel-titanium alloy. Nitinol is well known for its thermo-mechanical properties of superelasticity and shape memory effect. Shape memory refers to the ability of Nitinol to undergo deformation at one temperature and then recover its original, under-formed shape upon heating above its transformation temperature.
Super elasticity occurs at a narrow temperature range just above its transformation temperature; in this case, no heating is necessary to cause the under-formed shape to recover, and the material exhibits enormous elasticity, some 10-30 times that of ordinary metal.
Nitinol Wire & Nitinol Rod Features:
- Values listed are for full martensite to austenite transition.
- Hysteresis can be significantly reduced by partial transformation or ternary alloys.
- Similar to 300 series stainless steel or titanium
- Highly nonlinear with temperature
All incoming Nitinol raw materials are ensured that they meet proprietary internal specifications for chemistry, ingot transformation temperature, material homogeneity, and microstructure. Optimized to promote an exceptionally smooth and uniform surface finish quality, all wire products utilize a proprietary single and multi-crystalline diamond drawing die technology. Medical grade Nitinol Wire may be purchased in the cold worked (CW) or the super-elastic condition (SE) and after the correct superelastic heat treatment will accommodate strain up to 8% without permanent deformation at body temperature.
Nitinol Wire & Rod Specifications
|
Product Name |
Nitinol Wire |
Nitinol Rod |
|
Size |
Round Wire: 0.0004”-0.20” Dia. |
0.2” to 5.1” Dia. |
|
Flat Wire: W/T ~ 12 Thickness: ≥0.0004"; Width: ≤0.450" |
||
|
Forms |
Straight wires, Coils, Spools |
Straight rods |
|
Other Available Geometries |
Square/Rectangular wire and other customized shapes |
Bar, or customized |
Mechanical Properties for Superelastic Grades
|
|
Cold Worked |
Superelastic |
||||||
|
Grade |
Ingot As (℃) |
Min. Uts (psi) |
Elongation (%) |
Min. Uts (psi) |
Elongation (%) |
Loading Plateau (ksi) |
Unloading Plateau (ksi) |
Active Af (℃) |
|
Nitinol #1 |
-35 to -10 |
220,000 |
>4 |
180,000 |
>10 |
>70,000 |
>20,000 |
+10 to +18 |
|
Nitinol #2 |
-45 to -15 |
250,000 |
>4 |
210,000 |
>10 |
>80,000 |
>35,000 |
0 to +18 |
|
Nitinol #4 |
-10 to +10 |
220,000 |
>4 |
180,000 |
>10 |
>65,000 |
>7,000 |
+14 to +22 |
|
Nitinol #9 |
≥ +35 |
220,000 |
>4 |
160,000 |
>10 |
>75,000 |
>25,000 |
≤0 |
Mechanical Properties for Shape-Memory Grades
|
|
Cold Worked |
Superelastic |
||||||
|
Grade |
Ingot As (℃) |
Min. Uts (psi) |
Elongation (%) |
Min. Uts (psi) |
Elongation (%) |
Loading Plateau (ksi) |
Unloading Plateau (ksi) |
Active Af (℃) |
|
Nitinol #5 |
≥ +85 |
220,000 |
>3 |
160,000 |
>10 |
N/A |
N/A |
≥ +85 |
|
Nitinol #6 |
+35 to +85 |
220,000 |
>3 |
160,000 |
>10 |
N/A |
N/A |
+40 to +80 |
|
Nitinol #8 |
+10 to +35 |
220,000 |
>3 |
160,000 |
>10 |
N/A |
N/A |
+22 to +40 |
Surface Finishes:
Light Oxide (LO) Gold to Brown color - diamond-drawn surface
Dark Oxide (DK) Blue to Black color - diamond drawn surface
Black Oxide (BLK) Shiny Black color - diamond drawn surface
Etch (E) Chemical removal of oxide layer - maintain a smooth surface
Pickled (P) Chemical removal of the oxide layer along with a slight amount of base metal - the surface will have a rough texture Etched and Mechanically Polished (EMP) Chemical removal of the oxide layer followed by mechanical polish - the surface will have a Stainless Steel appearance although at > 40x magnification micro scratches are present.
Nitinol Wire & Rod Applications
Nitinol Wire is used for many different medical and industrial applications. The table below gives some typical engineering applications for each of our standard Nitinol medical grades:
- Nitinol Wire is used in guidewires, stents, stylets, forming mandrels, stone retrieval baskets, orthodontic files, etc.
- Nitinol Wire is often used in applications that require a high loading and unloading plateau stress at room temperature. Chromium-doped for decreased transformation temperature and increased tensile strength.
- Nitinol Wire is used in applications requiring increased stiffness. Cobalt-doped for decreased transformation temperature and increased tensile strength.
- Nitinol Wire provides the best cycling performances at body temperature (37°C).
- A common application for Nitinol alloy is high-temperature actuators.
- Nitinol Wire/Rod can be used in a very cold temperature environment.
Nitinol Wire & Nitinol Rod Packaging
Our products are packaged in customized cartons of various sizes based on the material dimensions. Small items are securely packed in PP boxes, while larger items are placed in custom wooden crates. We ensure strict adherence to packaging customization and the use of appropriate cushioning materials to provide optimal protection during transportation.
Packaging: Carton, Wooden Box, or Customized.
Magic Shape Memory Nitinol Wire Experiment
Nitinol Wire & Rod Packaging
Our Nitinol Wire and Nitinol Rod are clearly tagged and labeled externally to ensure efficient identification and quality control. SAM is your reliable nitinol wire supplier. Great care is taken to avoid any damage which might be caused during storage or transportation.
FAQs
Q1. What is Nitinol Wire & Rod?
Nitinol is a nickel-titanium (Ni-Ti) alloy known for its shape memory effect and superelasticity. Nitinol wire and rod are widely used in medical, aerospace, and industrial applications due to their unique properties.
Q2. What are the key properties of Nitinol?
Shape Memory Effect (SME): Returns to its original shape when heated.
Superelasticity: Can undergo large deformations and recover instantly.
Corrosion Resistance: Excellent resistance to oxidation and wear.
Biocompatibility: Suitable for medical implants and devices.
Q3. What are the main applications of Nitinol Wire & Rod?
Medical Devices: Stents, guidewires, orthodontic wires, and surgical instruments.
Aerospace & Robotics: Actuators, adaptive structures, and temperature-sensitive components.
Industrial & Consumer Products: Smart materials, eyeglass frames, and sensors.
